Electric Sesame Candy Slitting Machine , Ice Cream Packing Machine

Description

Sesame Candy Slitting Machine,ice cream packing machine

Packing Machine Application

Dession automatic liquid packing machine is suitable for the sachet / bag / pouch packing of variety of liquids,slurries,pastes, such as water, juice, Honey, cream, sauce, milk, reagent, pesticide emulsion, dyes, pigments and etc.

SPECIFICATIONS FOR LIQUID PACKING MACHINE
Model	DS-320Y
Measuring Range	50~ 500ml
Packaging Speed	30 ~ 70 bags/min
Bag Width	20 ~ 150mm
Bag Length	40 ~ 240mm
Film Roll Width	Max.300mm
Power	220V,50HZ,1.2KVA
Machine Size	(L)110 x (W) 755 x(H) 1540mm
Machine Weight	300KG

Packing Machine Function & Characteristic:

1). Attractive bag type to satisfy your high demand; Bag type like pillow bag, standing-up bags, Gusset bags, linking bags etc;

2). It completes bagging, filling, sealing, date printing, punching, counting automatically, saving labor and time;

3). Film drawing down system controlled by Servo Motor, Film rectifying deviation automatically, saving time and film material;

4).Digital big touching color screen display with numberial settings and flexible operation;

5). Imported PLC control system and Pneumatic system for vertical and horizontal sealing;

6). Easy to operate and low maintenance, compatible with different internal or external measuring device;

7).PID independent control of temperature, more suitable for different packing material.

8).Multiple automatic alarming functions make the loss to the minimum;

9).Dual encoders enable more stable performance; Available with inflatable device enables broad application;

10).Automatic correct function and intelligent operation save time,labor and film;

11).External film placing makes more sample and easier installation of packing film.

12).Multipurpose packing, suitable for various packing of similar product.

Detailed Images

Liquid pump, the filling weight is adjusted,the texture of the machine is 304 stainless steel for the material contact parts.It is safe and meets with the GMP standard.
